Design and construction of the 2 nd HDD was completed within 2 months. Directional boring, commonly called horizontal directional drilling or HDD, is a method of installing underground pipeline and conduits along a prescribed bore. After completion of the 4,200 long steel HDD, JEA added a second HDD for installation of an additional 800 feet of 36-inch HDPE pipe to the north of the northern end of the first HDD.
The HDD alignment traversed through vertical and horizontal curves and was drilled using conductor casings at both ends using the intersect method. Michelle reviewed geotechnical explorations and performed HDD design calculations including iterative hydrofracture calculations, pipe stress calculations and pullback calculations for both the steel pipe and the HDPE pipe for both installation stresses and operational stresses. Horizontal Directional Drilling is a radical improvement to the underground utility industry, because instead of drilling vertically, we use horizontal drilling. restrictions, a historical museum and FDOT concerns regarding drilling between and below the piles supporting the expressway. It has gained interest mainly due to the fact that HDD projects do not involve digging up entire stretches of roads, though the entry and exit points have to be dug and cordoned off. Selection of the alignment was constrained by discovering abandoned gantry rails/piles, contaminated soils and a grout containment wall in the parking lot, by r.o.w. Horizontal directional drilling (HDD) is becoming widely accepted in the construction industry as a convenient way to get a pipeline drilling job done with minimum disruption to everyday life.
Hdd horizontal directional drilling full#
We have a full line of products to suit your HDD. The HDD alignment starts in the highly used parking lot of Everbank Field (home of the Jacksonville Jaguars), crosses under a detention pond, Gator Bowl Boulevard, Commodore Point Expressway, a bulkhead and the St Johns River. provides you with the equipment and supplies you need to bore it right the first time. The HDPE pipe was for a pressurized sewer transmission pipeline.
The project included 4,200 feet of 36-inch diameter HDPE carrier pipe inside a 42-inch steel casing pipe installed by HDD under the St Johns River. Michelle was the trenchless design engineer for preliminary planning and final design for a design/build project in Jacksonville, Florida. JEA, South Shores HDD crossing of the St Johns River, Jacksonville, Florida.
